FAQ

Frequently asked questions

Services

Do you detect pathogens?

Yes, at the moment we have 18 primer sets available to target certain taxonomy group of bacteria and pathogens.

What services do you offer?

In Resistomap we provide antibiotic resistance monitoring services starting from sampling to the final analysis of the SmartChip qPCR results.

Do you perform DNA extraction?

Yes, we offer DNA extraction service for isolating environmental DNA from any sample type. We use commercial DNA isolation kits from QIAGEN and automate the process of DNA extraction using a QIACube machine. We store leftover samples for one month, after which the samples will be discarde.

We have the DNA samples, but they are not diluted. Can we send ourDNA samples without diluting them to the required concentration?

Yes, you can still send us your DNA samples. However, there will be an extra dilution service fee.

Do you provide further or custom analysis of the SmartChip qPCRmeasurement results?

Yes, if the primer sets are already validated, have annealing temperatures of 60 °C in quantitative PCR, and a positive control of the gene is available.

How long is the analysis process?

We deliver analysis results within 10 working days. For three or more chips, the analysis process may take longer.

Samples &
Shipment

How to send DNA samples to Resistomap?

For sample shipment instructions, please contact elina@resistomap.com or mina@resistomap.com

Which sample types do you accept?

We accept all types of samples, e.g., soil, sediment, sludge, manure, stool, meat, tissue, swabs, river, lake, wastewater, and seawater.

What is the required volume of liquid samples?

We require 1-10 L of water for river, lake, and seawater samples. For wastewater, we require 100 mL from influent and 250 mL from effluent. The sample should be filtered/concentrated using a hydrophilic membrane filter with a pore size of 0.2 µm. We recommend using PES membrane. Each concentrated water-filter should be stored in an individual 50 mL-falcon tube and delivered on dry ice to our facility in Helsinki, Finland.

What is the required weight of solid samples?

For solid samples, we recommend a dry/wet weight of 1 g. The solid samples should be stored in a zip lock plastic bag or a safe-lock 1.5 mL microtube and delivered on dry ice to our facility in Helsinki, Finland.

Our DNA samples are ready, what is the required volume and concentrationof DNA samples?

We require 10 ng/ul and 100 ul of volume measured using NanoDrop One for optimal SmartChip qPCR analysis of over 100 genes, with DNA quality of 260/280 between 1.8-2.0 +/- 0.1. For chip analysis of less than 100 genes: the minimum volume of samples is 50 uL. If you have samples with low amounts of DNA, the minimum DNA concentration is 3 ng/uL. We recommend diluting samples to molecular grade qPCR water. Please include an aliquote of your water, in case non-template control (NTC) sample is included to the analysis. Optimal sample concentrations and qualities help us ensure that you get the best results. Dilution service fee will be charged if samples are above the suitable concentrations and require dilution before the analysis. Dilution service fee is starting from 80€/chip analysis, increasing based on the number of samples.

How to prepare the DNA samples to be delivered to Resistomap?

We recommend using safe-lock 1.5 mL microtubes to avoid evaporation or spilling during transportation. Please label the tubes individually in numerical order only, e.g., 1-25. DO NOT USE PCR tubes for sending your samples. ‍We do not recommend sending samples on 96-well plates. Based on our experience there is more cross contamination during transport compared to when sending samples on individual 1.5 ml microcentrifuge tubes. If you using microcentrifuge tubes is not possible, please follow the pipetting order shown in this template: (Link to template)Finally, please provide information about your samples in the Sample specification sheet, which we will send you before you send the samples.

Can we get back the leftover DNA samples after the analysis?

No, usually there are only a few uL leftover from DNA samples after the SmartChip qPCR analysis. However, if you order the DNA extraction service at our facility, we can send back the leftover DNA extraction samples.

Can you organise the sample pickup and transport for us?

Yes, we can organise the sample pickup and transport for you using our courier partner DHL.

Is there anything that needs to be considered when sending samples forDNA extraction and analysis on dry ice?

When sending samples with dry ice the following things need to be considered: the local regulations, as there might be restrictions regarding shipments with dry ice; the samples need to be packed in a styrofoam box which will go inside a cardboard box. UN1845 label is needed on the side of the box with the weight of the shipped dry ice. Please be careful and wear protective gloves when handling the dry ice as careless handling might lead to frostbites.

When should I send the samples?

Monday, to avoid any unnecessary delays in the shipment.

qPCR Analysis

Do you detect pathogens?

Yes, at the moment we have 18 primer sets available to target certain taxonomy group of bacteria and pathogens.

Which genes do you measure? Can we choose the target genes?

In each chip analysis, we can measure up to 384 genes, including 16S rRNA gene (positive control); antibiotic resistance genes (ARGs) targeting aminoglycoside, amphenicol, beta lactam, florphenicol, multidrug efflux-pump, macrolide-lincosamide-streptogramin B (MLSB), trimethoprim, tetracycline, vancomycin; genes targeting other antibacterials such as nisin, bacitracin, antiseptic, mercury; and genes that are associated with mobile genetic elements (MGEs) and integrons.

Yes, you can customise the target genes with an extra customisation fee. The customisation options for chip analysis are: 296 Genes: 5 Samples; 248 Genes: 6 Samples; 216 Genes: 8 Samples; 144 Genes: 12 Samples; 120 Genes: 14 Samples; 96 Genes: 18 Samples; 80 Genes: 21 Samples; 72 Genes: 24 Samples; 54 Genes: 32 Samples; 48 Genes: 36 Samples; 36 Genes: 48 Samples; 24 Genes: 72 Samples; and 12 Genes: 128 Samples. You can choose the target genes based on over 600 previously validated primer sets that are available in our database from the the ARG selection sheet that we will send you separately.

How are the genes measured?

The ARG 1.0 and ARG 2.0 primer sets were developed to detect and quantify up to 384 genes in parallel and in one measurement using the SmartChip Real-Time PCR system. We updated the 384 gene ARG 2.0 primer sets to the ARG 2.1 primer sets according to the current antibiotic resistance gene database (CARD) to mantain the specificity of primer sets.

What is the final concentration of DNA sample that is analysed in eachqPCR reaction in the SmartChip qPCR measurement?

For sample with optimal 10ng/uL concentration a total of 2 ng/uL of DNA sample is measured in each 100 nL qPCR reaction

Can we measure the copy numbers of target genes?

Yes, you can measure the gene copy numbers by providing at least four to five serially diluted samples as the standard curve of the target gene. The standard curve samples will be measured with the other samples in the same chip analysis. You can calculate the target gene copy numbers based on the Ct values of the diluted samples used as the standard curve.

How do you account for variation in the genes in the primer design?

Each primer set was designed to target a specific region in an antibiotic resistance gene (ARG). For ARG variations, more primers have been designed to cover all known ARG variations.

How quickly do you add new genes to your offering?

It takes at least 1-3 months to optimise and validate new genes. Providing us the positive control of the new gene will make the validation process faster.

Can you add custom targets to the SmartChip qPCR measurement?

Yes, if the primer sets are already validated, have annealing temperatures of 60 °C in quantitative PCR, and a positive control of the gene is available.

Results

When we choose the SmartChip qPCR service with data analysis, the resultsare delivered via Resistomap Platform. What is Resistomap Platform?

Resistomap Platformis an online intearctive dashboard, which displays the numbers, abundances, and copy numbers of detected genes relative to the 16S rRNA genes, as well as a heatmap of gene profiles. You can filter the results according to your interest e.g., view gene abundances for a certain group of antibiotics or view results by sample type by clicking the shift button. With Resistomap Platform, you can share and present the results effciently to your colleagues by giving them access to your project.

In what format are the results provided?

The results are provided as a raw data in .xlsx format or as an interactive dashboard if you choose to use our analysis service Resistomap Platform.

How long is the analysis process?

We deliver analysis results within 10 working days. For three or more chips, the analysis process may take longer.

Are the results binary or quantitative?

The result can be used for both binary and quantitative studies. However, the quantification is based on the abundance of the genes or gene copy numbers relative to the amount of 16S rRNA gene in each sample.

How is the relative quantification performed?

We use the delta Ct calculation (https://doi.org/10.1021/acs.est.7b00551). Delta Ct = Ct of genes - Ct  of 16S rRNA gene. The relative quantification is calculated with formula: 2^-delta Ct.

Can we measure the copy numbers of target genes?

Yes, you can measure the gene copy numbers by providing at least four to five serially diluted samples as the standard curve of the target gene. The standard curve samples will be measured with the other samples in the same chip analysis. You can calculate the target gene copy numbers based on the Ct values of the diluted samples used as the standard curve.

Resistomap Platform

Are the results binary or quantitative?

The results from SmartChip qPCR measurement are relative abundances to 16S rRNA genes. In Resistomap Platform, the gene copy numbers are estimated gene abundances against known copy numbers of 16S rRNA genes in each sample. To calculate copy numbers of 16S rRNA genes in each sample, we measure the standard curve for 16S rRNA genes in the SmartChip qPCR measurement.

What is the Resistomap Platform and why should I use it?

Resistomap Platform is an online intearctive dashboard, which displays the numbers, abundances, and copy numbers of detected genes relative to the 16S rRNA genes, as well as a heatmap of gene profiles. You can filter the results according to your interest e.g., view gene abundances for a certain group of antibiotics or view results by sample type by clicking the shift button. With Resistomap Platform, you can share and present the results effciently to your colleagues by giving them access to your project.

Do you provide analysis of the SmartChip qPCR measurement results?

Yes, we can analyse raw data from the SmartChip qPCR measurement to provide meaningful gene abundances in each sample. We deliver the analysis results via Resistomap Platform, an interactive online dashboard, which displays the numbers, abundances, and copy numbers of detected genes relative to the 16S rRNA genes, as well as a heatmap of gene profiles.
